CodonFM (Encodon)

License: CodonFM (Encodon) uses Apache-2.0 for code and Custom (NVIDIA Open Model License) for model weights. Please refer to the code license and model weights license for full terms.

Proto is not affiliated with NVIDIA, Arc Institute, and University of California, San Francisco. This toolkit is open source and builds on the implementations produced by these organizations. Product names, logos, and trademarks are the property of their respective owners.

GitHub 88 GitHub 88

HuggingFace

HuggingFace Preprint Preprint Cite Cite Tool Source Tool Source Open as Notebook Open as Notebook Open on Proto Open on Proto

NVIDIA-BioNeMo/CodonFM

A family of codon-resolution language models trained on 130 million protein-coding sequences from over 20,000 species.

88 stars

View repo

NV-CodonFM-Encodon-80M-v1

NV-CodonFM-Encodon-600M-v1

NV-CodonFM-Encodon-1B-v1

NV-CodonFM-Encodon-Cdwt-1B-v1

Read preprint

@article{codonfm2025,
  title={Learning the language of codon translation with CodonFM},
  author={Darabi, Sajad and Cao, Fan and Naghipourfar, Mohsen and Rabi, Sara and Sethia, Ankit and Gion, Kyle and Grewal, Jasleen and Cohen, Jonathan and Greenleaf, William and Goodarzi, Hani and Sundaram, Laksshman},
  year={2025},
  publisher={NVIDIA},
  url={https://research.nvidia.com/labs/dbr/assets/data/manuscripts/nv-codonfm-preprint.pdf}
}

Copy citation

evo-design/proto-tools/proto_tools/tools/masked_models/codonfm

View source

Open Notebook

Open notebook

CodonFM Embeddings CodonFM Fitness CodonFM Gradient CodonFM Sampling CodonFM Mutation Score

Toolkit contributors

Function	Description
`run_codonfm_embeddings()`	Extract final-layer CLS embeddings for coding sequences with the CodonFM/Encodon model (GPU)	Docs Source
`run_codonfm_fitness()`	Score coding-sequence fitness with the upstream CodonFM/Encodon visible-token objective (GPU)	Docs Source
`run_codonfm_gradient()`	Compute the CodonFM/Encodon masked pseudo-log-likelihood gradient for relaxed coding sequences (GPU)	Docs Source
`run_codonfm_sample()`	Resample a subset of codons in coding sequences with the CodonFM/Encodon model (GPU)	Docs Source
`run_codonfm_score()`	Score codon substitutions by ref-vs-alt log-likelihood ratio with the CodonFM/Encodon model (GPU)	Docs Source

Background

Encodon is a BERT-style Transformer encoder trained with a masked-language-modeling objective over codon tokens (Darabi et al., 2025). Each coding sequence is split into in-frame codons, a fraction of codon tokens are masked, and the model predicts the original codon from its full bidirectional context. Because the vocabulary is codons rather than amino acids, the model learns the language of codon translation — which synonymous codon is expected in a given context — and not only the encoded protein. The released family spans four checkpoints (80M, 600M, 1B parameters, plus a codon-frequency-aware-masking 1B variant), all reading sequences up to 2048 tokens, i.e. coding sequences up to (2048 - 2) × 3 = 6138 nt after the CLS/SEP tokens.

Tools

CodonFM Fitness (`codonfm-fitness`)

Runs the upstream Encodon fitness routine: one unmasked forward pass, followed by the mean log-probability assigned to each visible non-padding input token. The mean includes the CLS and SEP special tokens as well as the codons. Higher is more model-typical, but this score is not masked pseudo-log-likelihood.

API Reference

Source

Input: CodonSequenceInput

List[string]

required

Coding sequence(s) at codon resolution. A single string is normalized to a one-item list; U maps to T and each length must be a multiple of 3 (codon-aligned) and at most 6138 nt.

Source

Config: CodonFMFitnessConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

Random seed. When set, tools run reproducibly up to small GPU float noise (see BaseToolOutput.approx_equal), and the seed participates in cache keys. When None, cacheable seed-sensitive tools skip cache until seeded.

enum

default:"encodon_80m"

Encodon checkpoint to run.Available options: encodon_80m, encodon_600m, encodon_1b, encodon_1b_cdwt

integer

default:"1"

Sequences processed per GPU forward pass.

Source

Output: CodonFMFitnessOutput

List[CodonFMFitnessResult]

Per-sequence fitness predictions.

Show CodonFMFitnessResult

string

required

Coding sequence that was scored (DNA alphabet).

integer

required

Length of the scored sequence in nucleotides.

number

required

Mean per-token log-likelihood under Encodon; higher is more model-typical (a proxy for a well-formed, natural coding sequence).

Applications

Sequence fitness is a zero-shot naturalness score for ranking or filtering coding sequences: comparing codon-optimized designs against wild type, screening synthetic constructs, or scoring candidate CDS variants without any task-specific training.

Usage Tips

Fitness is a relative score against Encodon’s training distribution, not an absolute quantity. It is most meaningful when comparing related sequences of similar length; the per-token mean already normalizes for length, but very short sequences are noisy.
batch_size trades memory for throughput. Lower it if you OOM on long CDS, raise it for short sequences.

CodonFM Score (`codonfm-score`)

Scores individual codon substitutions by the reference-vs-alternate log-likelihood ratio at the mutated position. The reference codon is masked and the model’s log-probability of the reference and alternate codons is compared; a positive llr (ref − alt) means the model favors the reference and the substitution is model-disfavored.

API Reference

Source

Input: CodonFMScoreInput

List[CodonFMMutation]

required

One or more codon substitutions, each against its own reference coding sequence.

Show CodonFMMutation

string

required

The reference coding sequence (codon-aligned DNA/RNA).

integer

required

1-based codon position of the substitution within sequence.

string

required

Reference codon at codon_position (must match sequence).

string

required

Alternate codon substituted at codon_position.

Source

Config: CodonFMScoreConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

enum

default:"encodon_80m"

Encodon checkpoint to run.Available options: encodon_80m, encodon_600m, encodon_1b, encodon_1b_cdwt

integer

default:"1"

Mutations processed per GPU forward pass.

Source

Output: CodonFMScoreOutput

List[CodonFMMutationResult]

Per-mutation log-likelihood-ratio scores.

Show CodonFMMutationResult

string

required

Reference coding sequence used as model context.

integer

required

Length of the reference sequence in nucleotides.

integer

required

1-based codon position of the substitution.

string

required

Reference codon.

string

required

Alternate codon.

number

required

Model log-likelihood of the reference codon at the site.

number

required

Model log-likelihood of the alternate codon at the site.

number

required

Log-likelihood ratio ref - alt; positive means the model favors the reference and the substitution is model-disfavored.

Applications

The masked log-likelihood ratio is a canonical zero-shot variant-effect estimator. Because Encodon is codon-level, it discriminates synonymous substitutions (same amino acid, different codon) that an amino-acid model cannot see — useful for studying codon-usage effects on expression and mRNA stability.

Usage Tips

Each mutation carries its own reference sequence, codon position (1-based), and ref/alt codons. The reference codon is validated against the sequence at that position, so an off-by-one frame error is caught before dispatch rather than silently mis-scored.
Scores are position-conditional. The same substitution scored in different sequence contexts will differ; that context-dependence is the point.

CodonFM Embeddings (`codonfm-embedding`)

Returns the final-layer CLS-token embedding for each coding sequence — a fixed-length learned representation whose dimensionality follows the checkpoint.

API Reference

Source

Input: CodonSequenceInput

List[string]

required

Coding sequence(s) at codon resolution. A single string is normalized to a one-item list; U maps to T and each length must be a multiple of 3 (codon-aligned) and at most 6138 nt.

Source

Config: CodonFMEmbeddingsConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

enum

default:"encodon_80m"

Encodon checkpoint to run.Available options: encodon_80m, encodon_600m, encodon_1b, encodon_1b_cdwt

integer

default:"1"

Sequences processed per GPU forward pass.

Source

Output: CodonFMEmbeddingsOutput

List[CodonFMEmbeddingResult]

Per-sequence CLS embeddings.

Show CodonFMEmbeddingResult

string

required

Coding sequence that was embedded (DNA alphabet).

integer

required

Length of the sequence in nucleotides.

List[number]

required

The final-layer CLS-token embedding vector (hidden size depends on the checkpoint: 1024 for 80M, 2048 for 600M/1B).

Applications

The CLS embedding is a codon-aware sequence descriptor for downstream supervised tasks (classification, regression, clustering) and similarity search over coding sequences.

Usage Tips

Different checkpoints produce different embedding sizes. Representations from one checkpoint do not transfer to another without re-fitting downstream models; pick one and keep it fixed for an analysis.

CodonFM Gradient (`codonfm-gradient`)

Computes the gradient of the mean masked negative log-likelihood with respect to a relaxed (L, 64) distribution over all 64 DNA codons, including the three standard stop codons (lexicographic order AAA, AAC, AAG, AAT, …). Each row’s current argmax codon is the masked-language-model target. The Encodon weights are frozen; the relaxed distribution passes through Encodon’s embedding layer and normalization, each codon position is masked in turn, and a per-chunk backward pass accumulates the gradient. An optional Straight-Through Estimator runs the forward on hard one-hot codons while routing gradients through the soft probabilities.

API Reference

Source

Input: CodonFMGradientInput

List[array]

required

Relaxed coding-sequence state with shape (L, 64) in lexicographic DNA codon order (AAA, AAC, AAG, AAT, ...; see :data:CODONFM_CODON_VOCAB). L must be ≤ 2046 (Encodon’s positional cap minus the CLS/SEP tokens); over-length inputs raise ValueError. Each row’s argmax codon is used as that position’s masked-language-model target.

number

default:"1.0"

Optional softmax temperature. When set, applies softmax(input / temperature) before computing the gradient. When None, every input row must already be a probability distribution.

Source

Config: CodonFMGradientConfig

enum

default:"encodon_80m"

Encodon weights variant.Available options: encodon_80m, encodon_600m, encodon_1b, encodon_1b_cdwt

boolean

default:"False"

Straight-Through Estimator: hard one-hot codons in the forward pass with gradients flowing through soft probabilities. When False, uses soft blended codon embeddings directly.

boolean

default:"True"

Run backward pass and return gradient. Set False for forward-only masked-log-likelihood scoring.

integer

default:"32"

Codon positions per forward pass for batched masked-PLL.

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device to run the model on.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

Source

Output: CodonFMGradientOutput

array

Gradient w.r.t. the input codon logits, or None when compute_gradient=False.

number

required

Mean masked negative log-likelihood over codon positions.

Dict[string, any]

Log-likelihood, perplexity, sequence length, and objective details.

List[string]

required

Codon column ordering for the input logits and returned gradient.

Applications

This exposes Encodon as a differentiable, codon-level naturalness prior for continuous sequence design — usable inside gradient descent, MCMC, or any optimization loop over relaxed coding sequences (e.g. codon optimization with a learned constraint).

Usage Tips

temperature converts the raw input into a per-position distribution. The default 1.0 applies softmax(logits / T); set it to None only when every row is already a non-negative probability distribution summing to 1.
use_ste enables the Straight-Through Estimator for stronger guidance toward discrete codons while keeping a usable gradient.
compute_gradient=False runs forward-only. The gradient field is None but loss and metrics are still populated. This is a masked pseudo-log-likelihood objective; it is distinct from the visible-token objective returned by codonfm-fitness.

CodonFM Sampling (`codonfm-sample`)

Resamples a subset of codons in a coding sequence. A number of codon positions (num_mutations, or mask_fraction of the codons) are chosen at random, masked, and refilled from Encodon’s distribution over the 61 sense codons in a single forward pass. The sequence length is preserved and sampling cannot introduce a new stop codon. It can replace an existing stop if that position is selected, so keep a required terminal stop outside the editable region or restore it afterward.

API Reference

Source

Input: MaskableCodonSequenceInput

List[string]

required

Coding sequence(s) at codon resolution, optionally with whole codons masked as ___ to choose which positions are resampled.

Source

Config: CodonFMSampleConfig

enum

default:"encodon_80m"

Encodon checkpoint to sample from.Available options: encodon_80m, encodon_600m, encodon_1b, encodon_1b_cdwt

RandomMaskingStrategy

Which codons to resample, counted in codons rather than nucleotides. Ignored when the input already carries ___ masks, which name the positions outright. fixed_positions pins codons that must survive, which is how a start or stop codon is kept intact.

Show RandomMaskingStrategy

string

default:"random"

Position-selection method. Always "random" for this tier (uniform selection, no model).

integer

Exact number of positions to mask per sequence.

number

Fraction of designable positions to mask (e.g. 0.15 for ~15%).

array

1-indexed positions that must NOT be masked. Applied uniformly to all sequences.

number

default:"1.0"

Softmax temperature for codon sampling; higher is more diverse.

integer

default:"1"

Number of (same-length) sequences per GPU forward pass.

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for CodonFM inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

Source

Output: CodonFMSampleOutput

List[CodonFMSampleResult]

One resampled coding sequence per input.

Show CodonFMSampleResult

string

required

Resampled coding sequence in the DNA alphabet.

Applications

Masked-codon resampling is the local-edit primitive behind coding-sequence design: it proposes model-plausible synonymous or missense codon changes for directed-evolution / MCMC / genetic-algorithm loops (e.g. as the mutation generator in a Proto Language optimizer, paired with the codonfm-fitness constraint).

Usage Tips

num_mutations overrides mask_fraction. It sets an exact number of positions to resample, not a guaranteed Hamming distance: the model can draw the original codon again.
temperature controls diversity. Below 1.0 sharpens toward the model’s favorite codon; above 1.0 broadens exploration. Because sampling is stochastic, pass a seed for reproducible proposals.

Toolkit Notes

These apply to every CodonFM tool in this toolkit (codonfm-fitness, codonfm-score, codonfm-embedding, codonfm-gradient, codonfm-sample).

Checkpoints download on demand. The nvidia/NV-CodonFM-Encodon-*-v1 repos are public; the standalone worker fetches the .safetensors weights and their config.json on first use and caches them. No HuggingFace token is required (one is used automatically if present).
A CUDA GPU is required. The pinned upstream Encodon attention implementation uses xFormers kernels that do not provide a CPU execution path.
Inputs are codon-aligned nucleotide sequences. Each length must be a multiple of 3; RNA U is mapped to T, while ambiguous bases such as N are rejected because upstream tokenization would shift codon positions. Inputs are not checked for a start codon, terminal stop, internal stops, or coding-strand orientation.
Max sequence length is 6138 nt (2046 codons). Encodon’s positional cap is 2048 tokens; longer inputs raise ValueError rather than truncating.
The default checkpoint is encodon_80m. It is the fastest; the 600M/1B checkpoints trade throughput for fidelity. Pick a larger one for final scoring.

Example notebook: See the full working example for a copy-paste-ready walkthrough.

Infrastructure Guides

The following guides cover how to run tools efficiently and at scale.

Tool Persistence

Keep a tool’s model warm across calls instead of reloading it every invocation.

Device Management

How GPUs are allocated to tools and how to target specific devices.

Parallel Execution

Fan a batch of inputs out across multiple GPUs.

Tools

Guides

Tool Catalog

Concepts

Implementing a Tool

CodonFM (Encodon)

Background

Tools

CodonFM Fitness (`codonfm-fitness`)

API Reference

Applications

Usage Tips

CodonFM Score (`codonfm-score`)

API Reference

Applications

Usage Tips

CodonFM Embeddings (`codonfm-embedding`)

API Reference

Applications

Usage Tips

CodonFM Gradient (`codonfm-gradient`)

API Reference

Applications

Usage Tips

CodonFM Sampling (`codonfm-sample`)

API Reference

Applications

Usage Tips

Toolkit Notes

Infrastructure Guides

Tool Persistence

Device Management

Parallel Execution

​Background

​Tools

​CodonFM Fitness (codonfm-fitness)

​API Reference

​Applications

​Usage Tips

​CodonFM Score (codonfm-score)

​API Reference

​Applications

​Usage Tips

​CodonFM Embeddings (codonfm-embedding)

​API Reference

​Applications

​Usage Tips

​CodonFM Gradient (codonfm-gradient)

​API Reference

​Applications

​Usage Tips

​CodonFM Sampling (codonfm-sample)

​API Reference

​Applications

​Usage Tips

​Toolkit Notes

​Infrastructure Guides

Tool Persistence

Device Management

Parallel Execution

Background

Tools

CodonFM Fitness (`codonfm-fitness`)

API Reference

Applications

Usage Tips

CodonFM Score (`codonfm-score`)

API Reference

Applications

Usage Tips

CodonFM Embeddings (`codonfm-embedding`)

API Reference

Applications

Usage Tips

CodonFM Gradient (`codonfm-gradient`)

API Reference

Applications

Usage Tips

CodonFM Sampling (`codonfm-sample`)

API Reference

Applications

Usage Tips

Toolkit Notes

Infrastructure Guides
