RNA sequence design and protein—DNA specificity prediction with NA-MPNN
Andrew Kubaney
bioRxiv (2025)
Read preprint
Copy citation
evo-design/proto-tools/proto_tools/tools/sequence_scoring/na_mpnn_specificity
View source
Open Notebook
Open notebook
proto-tools on GitHub
Run locally with proto-tools
Toolkit contributors

​
Background

Sequence-specific DNA-binding proteins recognize their target sites through a combination of direct base contacts and indirect shape readout. Predicting the base preference a protein imposes at each position of a bound DNA site is central to engineering transcription factors, characterizing binding specificity, and designing synthetic regulatory elements such as repressors and promoters. NA-MPNN (Kubaney et al., 2025) is a message-passing neural network that represents proteins, DNA, and RNA within a single unified biopolymer graph, framing both RNA sequence design and protein–DNA binding specificity as nucleic-acid inverse-folding problems (recovering likely sequences for a fixed three-dimensional structure). For specificity prediction, the model conditions on a fixed-docked protein–DNA complex and emits per-position nucleotide probabilities over the DNA chains, which this toolkit canonicalizes into a DNA-only L x 4 PPM together with the recovered true sequence and chain labels.

​
Learning Resources

  • baker-laboratory/NA-MPNN. Official repository with the training and inference code, installation instructions, and usage examples.

​
Tools

​
NA-MPNN Specificity (na-mpnn-specificity)

Predicts the DNA base preference of a bound protein from one or more protein–DNA complex structures. For each input PDB, the tool runs NA-MPNN specificity inference, restricts the output to valid DNA positions, and returns a canonical PPM (L x 4, A,C,G,T order), the recovered true DNA sequence (indices 0..3), per-row masks, and chain labels. Each result is also written to a canonical .npz file whose path is returned in output_npz_path.

​
API Reference

Source
​
List[string]
required
PDB file paths for protein-DNA complexes to score. A bare string is normalized into a single-element list.
Source
​
integer
default:"8"
Batch size per inference call.
​
integer
default:"1"
Number of prediction batches to run.
​
number
default:"0.1"
Sampling temperature for NA-MPNN.
​
string
default:""
Residues to omit during NA-MPNN sampling.
​
boolean
default:"True"
Restrict design tokens to nucleic acid positions.
​
string
Optional directory for canonical NPZ artifacts.
​
boolean
default:"False"
Keep intermediate raw NA-MPNN output directories.
​
integer
default:"0"
Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.
​
string
default:"cuda"
Device to run inference on (inherited).
​
integer
default:"3600"
Maximum execution time in seconds. None waits indefinitely.
​
integer
Random seed. When set, tools run reproducibly up to small GPU float noise (see BaseToolOutput.approx_equal), and the seed participates in cache keys. When None, cacheable seed-sensitive tools skip cache until seeded.
Source
​
List[NAMPNNSpecificityResult]
required
Canonicalized result per input structure, index-aligned with pdb_paths.

​
Applications

This tool is appropriate for scoring and ranking candidate protein–DNA binder designs by their predicted specificity, for comparing the base preference of a designed binder against a target motif inside an optimization loop, and for characterizing the specificity landscape of natural or engineered DNA-binding proteins. The per-position PPM can be compared to a desired motif to drive specificity-based selection.

​
Usage Tips

  • The NA-MPNN checkout and checkpoint are provisioned for you. The standalone setup clones a pinned revision of the repository (which ships the specificity checkpoint in-tree) into the managed weights cache, so no repository or checkpoint path is configured. Point PROTO_NA_MPNN_SPECIFICITY_WEIGHTS_DIR at an existing checkout to reuse it. A run that uses device='proto' fails fast because these local resources cannot be staged.
  • predicted_ppm rows are DNA-only and renormalized. Only positions that are both valid and DNA are kept, and each row is renormalized over A,C,G,T, so the returned matrix already excludes protein and masked positions.
  • temperature controls sampling sharpness. Lower values (default 0.1) concentrate probability on the most-preferred base; raise it to soften the distribution.
  • output_directory and keep_intermediate control artifacts. Leave output_directory unset to write canonical .npz files to a temporary directory, or set it to persist them. Set keep_intermediate=True to retain the raw NA-MPNN output for debugging.

​
Toolkit Notes

  • NA-MPNN runs as an isolated standalone environment that shells out to the upstream NA-MPNN inference CLI; the heavy model dependencies stay out of the main environment.
  • The standalone setup clones a pinned NA-MPNN revision (with its in-tree specificity checkpoint) into the managed weights cache. If the clone cannot reach GitHub, the environment setup signals a clean test skip rather than a hard failure.
Example notebook: See the full working example for a copy-paste-ready walkthrough.

​
