Coevolutionary discovery using genome language models

Coevolutionary mining of prokaryotic non-coding elements with a genome language model

David B. Li, Garyk Brixi, … Brian L. Hie

bioRxiv (2026)

Read preprint

@article{li2026minerva,
  title     = {Coevolutionary mining of prokaryotic non-coding elements with a genome language model},
  author    = {Li, David B. and Brixi, Garyk and Kim, Alexandra S. and Fiamenghi, Mateus B. and Driscoll, Claudia L. and Evans, Simone A. and Gao, Alex and Ivanova, Natalia N. and Kyrpides, Nikos C. and Deisseroth, Karl and Wilkinson, Max E. and Fischbach, Michael A. and Hie, Brian L.},
  journal   = {bioRxiv},
  year      = {2026},
  doi       = {10.64898/2026.09.22.753630},
  url       = {https://www.biorxiv.org/content/10.64898/2026.09.22.753630},
  publisher = {Cold Spring Harbor Laboratory}
}

Copy citation

evo-design/proto-tools/proto_tools/tools/masked_models/minerva

View source

Open Notebook

Open notebook

Run locally with proto-tools

pip install git+https://github.com/evo-design/proto-tools.git

Toolkit contributors

Function	Description
`run_minerva_embeddings()`	Extract mixed protein/DNA embeddings and biological logits with Minerva (GPU)	Docs Source
`run_minerva_gradient()`	Differentiate masked pseudo-log-likelihood for relaxed mixed protein/DNA tokens with Minerva (GPU)	Docs Source
`run_minerva_interactions()`	Predict protein, RNA base-pairing, and repeat interaction maps with Minerva (GPU)	Docs Source
`run_minerva_sample()`	Sample mixed protein/DNA loci while preserving modality and strand markers with Minerva (GPU)	Docs Source
`run_minerva_score()`	Score mixed protein/DNA loci by masked pseudo-log-likelihood with Minerva (GPU)	Docs Source

Background

Many non-coding elements retain their structure or repeated organization despite substantial sequence divergence. Minerva reads out the coevolutionary patterns learned by a genome language model as separate maps of base pairing, protein contacts, and repeats. Each head combines attention features to predict its interaction type in a single forward pass, enabling rapid scans of genomic regions without constructing multiple sequence alignments.

Interaction head	Predicted relationship	Discovery use
`base_pairing`	Nucleotide pairing, evaluated on conserved RNA base pairs	Find candidate structured ncRNAs, hairpins, and extensions to annotated RNA structures
`protein`	Residue contacts within protein monomers	Examine protein structural signals alongside neighboring non-coding elements
`repeat`	Relationships between repetitive sequence motifs	Identify repeat arrays, including CRISPR-like and repetitive extragenic palindromic (REP) patterns

Speed makes genome-scale mining practical. In the Minerva study, the authors scanned 150 bacterial genomes in 100 minutes on one NVIDIA H100 GPU, plus 31 minutes to write the maps. That upstream workflow used overlapping 4096-token windows and the last-two-layer interaction heads; this tool exposes the inference step on prepared loci. The study used these maps to identify unannotated structured regions, extend the known TwoAYGGAY RNA architecture, and discover arrays of structurally conserved but sequence-diverse ncRNAs beside prophage UG27 reverse transcriptases. Experimental follow-up showed that the UG27 RNAs template short cDNA hairpins. These examples illustrate how interaction patterns can guide candidate selection, comparative analysis, and experimental discovery. See Li et al. (2026). Minerva-MLM was initialized from gLM2 and retains its mixed protein/DNA representation, with amino acids for coding regions, nucleotides for intergenic regions, and strand markers.

Tools

Minerva Interactions (`minerva-interactions`)

Predicts base-pairing, protein-contact, and repetitive-motif maps in a single model pass. Every selected head returns a labeled (L, L) probability matrix, with one result bundle per input locus.

API Reference

Source

Input: MixedSequenceInput

List[string]

required

Uppercase proteins and lowercase DNA, optionally separated by +/- strand markers (<+>/<-> are stored as +/-). A single string is normalized to a list.

Source

Config: MinervaInteractionsConfig

List[string]

Selected named interaction heads.

enum

default:"2"

Number of final transformer layers used by the heads.Available options: 2, 6

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for model inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

Random seed. When set, tools run reproducibly up to small GPU float noise (see BaseToolOutput.approx_equal), and the seed participates in cache keys. When None, cacheable seed-sensitive tools skip cache until seeded.

enum

default:"gbrixi/minerva-mlm"

Public model checkpoint.Available options: gbrixi/minerva-mlm, gbrixi/minerva-mlm-8k

integer

default:"1"

Equal-token-length sequences per forward pass; one limits matrix memory.

Source

Output: SequenceInteractionsOutput

List[SequenceInteractions]

required

Interaction bundles in input order.

Show SequenceInteractions

Dict[string, SequenceInteractionMap]

required

Named interaction probability maps.

Applications

Screen intergenic regions for structured ncRNAs and repeat arrays, inspect their organization around nearby genes, and prioritize unannotated loci for comparative analysis or experimental follow-up. Combining the base-pairing and repeat maps can highlight arrays of structured elements, as in the study’s UG27 discovery. The protein map adds monomeric contact predictions for the coding parts of the same locus.

Usage Tips

heads selects the returned channels. All three are returned by default. Select fewer to reduce output size; this does not change the meaning of an individual channel.
interaction_layers=2 is the fast screening default. It uses the final two transformer layers, as in the paper’s genome scans. The released six-layer variant (interaction_layers=6) offers slightly higher accuracy at greater memory and compute cost.
The axes include strand markers and ambiguous context. Padding is removed. Use axis_labels (one per input character) to select biological subregions; matrix indices are not genome coordinates. The tool returns the upstream probabilities without symmetrizing, thresholding, removing the diagonal, or combining strands.
plot() draws the maps. result.plot() overlays base pairing, repeats, and protein contacts in the Minerva publication colors, with a track marking genes, intergenic DNA, and strand markers; plot(channel="base_pairing") shows one map with a colorbar, and window=(start, end) zooms to 1-indexed positions. It returns a matplotlib figure.
Dense output grows quadratically with token count. Doubling the locus length quadruples each matrix’s element count. The default export is compressed NPZ, with keys such as 0_protein and 0_protein_axis_labels; arrays load with numpy.load(..., allow_pickle=False). JSON is also supported, and the public Python values remain nested lists.

Minerva Embeddings (`minerva-embedding`)

Returns one mean-pooled embedding per prepared locus, with optional logits over the 24 canonical protein/DNA tokens.

API Reference

Source

Input: MixedSequenceInput

List[string]

required

Uppercase proteins and lowercase DNA, optionally separated by +/- strand markers (<+>/<-> are stored as +/-). A single string is normalized to a list.

Source

Config: MinervaEmbeddingsConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for model inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

enum

default:"gbrixi/minerva-mlm"

Public model checkpoint.Available options: gbrixi/minerva-mlm, gbrixi/minerva-mlm-8k

integer

default:"1"

Sequences per forward pass.

boolean

default:"False"

Include token-aligned biological logits.

integer

default:"-1"

0=embedding table, 1..N=transformer output, -1=last layer.

Source

Output: MixedEmbeddingsOutput

List[MixedSequenceEmbedding]

required

Per-locus embedding bundles in input order.

Show MixedSequenceEmbedding

List[string]

Column order of optional biological logits.

List[number]

required

Mean-pooled embedding vector for one sequence.

List[integer]

required

Binary mask indicating valid positions (1) vs padding (0).

array

Optional per-token protein/DNA logits.

Projection2D

Optional 2D coordinate from a UMAP projection of all embeddings in the same call. Populated when n_sequences >= 4; None otherwise (single-point or 2-3-point UMAP is meaningless).

Applications

Cluster or retrieve candidate loci after an interaction-map screen, or use the pooled vectors as features in a downstream classifier. Keep the checkpoint and representation layer fixed when comparing embeddings.

Usage Tips

repr_layer=-1 selects the last transformer output. Layer 0 selects the input embedding table; positive indices select transformer outputs. Pooling includes every unpadded token, including strand markers.
return_logits=True adds an (L, 24) matrix. Columns follow ACDEFGHIKLMNPQRSTVWYacgt; these are raw logits, not normalized probabilities. The matrix includes strand-marker rows, one row per input character.
CSV, NPY, and PT exports contain pooled vectors. JSON also preserves vocab and optional logits for position-level analysis; logits rows follow the input sequence.

Minerva Scoring (`minerva-score`)

Computes masked pseudo-log-likelihood by masking each canonical protein or DNA position in turn and predicting its original token from the remaining context. Returns summed and mean log-likelihood, perplexity, and the positions included in the score.

API Reference

Source

Input: MixedSequenceInput

List[string]

required

Uppercase proteins and lowercase DNA, optionally separated by +/- strand markers (<+>/<-> are stored as +/-). A single string is normalized to a list.

Source

Config: MinervaScoringConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for model inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

enum

default:"gbrixi/minerva-mlm"

Public model checkpoint.Available options: gbrixi/minerva-mlm, gbrixi/minerva-mlm-8k

integer

default:"1"

Individually masked variants per forward pass.

boolean

default:"False"

Include masked biological logits; unscored context rows are zero.

Source

Output: MixedScoringOutput

List[MixedScoringMetrics]

required

Per-locus scores in input order.

Show MixedScoringMetrics

List[integer]

required

1-indexed canonical protein/DNA target token positions.

string

Name of the metric that best summarizes the result overall (e.g. "avg_plddt" for AlphaFold2). Used by downstream UI and reporting to pick a headline value.

string

Concrete Metrics subclass tag; enables typed reconstruction after a serialization round-trip.

array

Per-position logits array (seq_len, vocab_size). None unless return_logits=True.

array

Token ordering for logits.

Metrics (one set per scores item)

Metric	Type	Range	Availability
`log_likelihood`	float	≤ 0.0	always
`avg_log_likelihood`	float	≤ 0.0	always
`perplexity`	float	≥ 1.0	always

Applications

Rank related sequence variants with a contextual sequence prior. Scores reflect compatibility with the learned distribution and do not establish biological function or binding.

Usage Tips

scored_positions uses 1-indexed model-token positions. Strand markers and accepted ambiguous protein symbols provide context but are excluded from score targets and the mean’s denominator.
batch_size controls masked variants per forward pass. Scoring requires work proportional to the number of target positions; start with the default 1 when memory is limited.
Optional scoring logits come from masked passes. Their (L, 24) rows align with the input sequence; unscored marker and ambiguous-context rows are zero. These differ from the unmasked logits returned by embeddings.
PLL uses the full upstream vocabulary of 37 tokens. Exported logits contain only the 24 biological tokens, so applying softmax to those columns does not reproduce PLL.
Compare similar contexts. Higher mean log-likelihood and lower perplexity mean the model predicts the sequence more readily. Summed log-likelihood also depends on the number of scored positions.

Minerva Sampling (`minerva-sample`)

Refills selected protein and DNA positions while preserving their original modality, sequence length, strand markers, and noneditable ambiguous protein symbols. Each input produces one sampled locus.

API Reference

Source

Input: MixedSequenceSampleInput

array

One mapping per locus, assigning every mask’s 1-indexed token position to protein or DNA. Positions index the +/- form. Omit for fully specified sequences.

List[string]

required

Prepared loci, optionally carrying _ masks.

Source

Config: MinervaSampleConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for model inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

enum

default:"gbrixi/minerva-mlm"

Public model checkpoint.Available options: gbrixi/minerva-mlm, gbrixi/minerva-mlm-8k

integer

default:"1"

Sequences per forward pass.

MaskingStrategy

Select editable token positions when no explicit masks are supplied.

Show MaskingStrategy

number

default:"1.0"

Temperature for position selection. < 1.0 is greedy, 1.0 uses scores as-is, > 1.0 is more uniform. Only affects model-based methods.

enum

default:"random"

Scoring method for position selection. "random": uniform random, "entropy": highest model uncertainty, "max-logit": lowest model confidence.Available options: random, entropy, max-logit

integer

Exact number of positions to mask per sequence.

number

Fraction of designable positions to mask (e.g. 0.15 for ~15%).

array

1-indexed positions that must NOT be masked. Applied uniformly to all sequences.

enum

default:"single_pass"

Sampling algorithm.Available options: single_pass, iterative_refinement

number

default:"1.0"

Temperature within each editable position’s modality.

number

default:"1.0"

Nucleus threshold for iterative refinement.

integer

default:"20"

Number of iterative refinement rounds.

enum

default:"cosine"

Iterative unmask schedule.Available options: cosine, linear

enum

default:"random"

Random or confidence-based commitment selection.Available options: random, entropy

boolean

default:"True"

Cool temperature during iterative refinement.

boolean

default:"False"

Include biological logits from the completed sequence.

Source

Output: MixedSampleOutput

List[MixedSequenceSample]

required

Per-locus sampling bundles in input order.

Show MixedSequenceSample

List[string]

Column order of optional biological logits.

string

required

Completed mixed protein/DNA locus with original strand markers.

array

Optional per-token protein/DNA logits.

Applications

Propose local sequence edits for a design or variant-screening loop while keeping the prepared locus layout intact.

Usage Tips

Automatic masking uses MaskingStrategy. By default it selects about 30% of eligible canonical biological positions, with at least one when any are eligible. Set either num_mutations or mask_fraction; fixed_positions counts all model tokens, including markers. Entropy and max-logit selection use the same checkpoint as sampling.
Premasked inputs require mask_modalities. Supply one mapping per sequence that labels every _ position as "protein" or "dna". For example, +M_+a_ needs mask_modalities=[{3: "protein", 6: "dna"}]. Explicit masks bypass automatic selection for the batch.
The allowed alphabet is preserved per site. Protein positions sample among the 20 canonical amino acids; DNA positions sample among lowercase acgt. A selected position can draw its original token again, so the number of masks is not a guaranteed number of substitutions.
sampling_method selects the fill algorithm. single_pass fills all masks together. iterative_refinement progressively commits predictions and uses num_steps, schedule, strategy, top_p, and temperature_annealing. temperature controls sampling diversity and seed makes proposals reproducible.
Optional sampling logits describe the completed locus. They come from a final unmasked forward pass. Export prepared mixed strings as JSON or text; they are not nucleotide or protein FASTA records.

Minerva Gradient (`minerva-gradient`)

Returns the gradient of mean masked negative log-likelihood with respect to a relaxed (L, 24) sequence state. A fully specified sequence template fixes each position’s modality and the locations of strand markers and ambiguous protein context.

API Reference

Source

Input: MixedSequenceGradientInput

string

required

Fully specified template fixing modality and +/- strand markers.

List[array]

required

One 24-column row per model token in ACDEFGHIKLMNPQRSTVWYacgt order. Fixed context rows must be zero.

number

default:"1.0"

Softmax temperature; None requires probability distributions over the permitted modality and zero elsewhere.

Source

Config: MinervaGradientConfig

integer

default:"0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

string

default:"cuda"

Device used for model inference.

integer

default:"3600"

Maximum execution time in seconds. None waits indefinitely.

integer

enum

default:"gbrixi/minerva-mlm"

Public model checkpoint.Available options: gbrixi/minerva-mlm, gbrixi/minerva-mlm-8k

integer

default:"1"

Individually masked variants per forward and backward pass.

boolean

default:"False"

Hard forward tokens with soft-probability gradients.

boolean

default:"True"

Compute the gradient, or evaluate only the masked PLL loss.

Source

Output: MixedGradientOutput

array | array

Derivative of masked NLL with respect to the input state.

number

required

Mean masked negative log-likelihood.

Dict[string, any]

Masked PLL metrics and checkpoint metadata.

List[string]

required

Protein/DNA column order shared by input and gradient.

Applications

Use the masked-language-model objective as a differentiable prior in sequence optimization while retaining the original protein/DNA layout.

Usage Tips

The matrix axis includes every model token. Columns are ACDEFGHIKLMNPQRSTVWYacgt. Strand-marker and ambiguous-context rows must be zero; their returned gradients are also zero. Opposite-modality columns do not influence a position.
temperature=1.0 treats the input as logits. The worker applies a softmax within the position’s modality. With temperature=None, provide a nonnegative probability distribution within that modality and zeros elsewhere. one_hot_mixed_logits() builds a valid starting state from a template.
The objective masks canonical sites one at a time. The target at each site is its current discrete argmax token. use_ste=True uses hard forward tokens with soft derivatives; compute_gradient=False returns the objective with gradient=None.

Toolkit Notes

These apply to every Minerva tool in this toolkit.

Inputs are prepared, case-sensitive strings. Uppercase letters denote protein; lowercase acgt denotes DNA. The uppercase protein symbols X, B, U, Z, and O are accepted as fixed context. Lowercase ambiguous nucleotides, whitespace, literal <mask>, and other control tokens are rejected. Sampling accepts _ only with explicit modality metadata.
Strand markers are + (forward) and - (reverse). The upstream <+>/<-> spelling is also accepted and converted to +/-. Token positions are 1-indexed string indices of the +/- form, not genomic nucleotide coordinates. No case conversion, strand insertion, reverse complementation, translation, or gene calling is performed.
Prepare biologically appropriate orientation yourself. Upstream examples use + for intergenic DNA and strand markers for translated coding regions. The tool preserves the submitted orientation and does not combine strands.
Model setup and weights are managed automatically. The isolated environment is built on first use and public Hugging Face checkpoints are downloaded into the shared model cache. A Hugging Face token is not required for these public checkpoints.
Execution defaults to CUDA. Reduce batch_size when memory is limited. Repeated calls with one checkpoint can reuse a persistent worker through the standard ToolInstance.persist() API.
The default checkpoint is gbrixi/minerva-mlm. It accepts up to 4096 model tokens; gbrixi/minerva-mlm-8k accepts up to 8192. These counts include strand markers. Overlength inputs raise an error rather than truncating.
RNA base-pairing input uses the DNA alphabet. Submit lowercase acgt as in upstream examples; the tool does not convert u to t or call an RNA structure from the map.
Scope is prepared-string inference. Upstream gene calling, GenBank ingestion, fine-tuning, categorical Jacobians, and strand-ensemble workflows are not exposed by these tools.

Example notebook: See the full working example for a copy-paste-ready walkthrough.

Infrastructure Guides

The following guides cover how to run tools efficiently and at scale.

Tool Persistence

Keep a tool’s model warm across calls instead of reloading it every invocation.

Device Management

How GPUs are allocated to tools and how to target specific devices.

Parallel Execution

Fan a batch of inputs out across multiple GPUs.

Tools

Guides

Tool Catalog

Concepts

Implementing a Tool

Background

Tools

Minerva Interactions (`minerva-interactions`)

API Reference

Applications

Usage Tips

Minerva Embeddings (`minerva-embedding`)

API Reference

Applications

Usage Tips

Minerva Scoring (`minerva-score`)

API Reference

Applications

Usage Tips

Minerva Sampling (`minerva-sample`)

API Reference

Applications

Usage Tips

Minerva Gradient (`minerva-gradient`)

API Reference

Applications

Usage Tips

Toolkit Notes

Infrastructure Guides

Tool Persistence

Device Management

Parallel Execution

​Background

​Tools

​Minerva Interactions (minerva-interactions)

​API Reference

​Applications

​Usage Tips

​Minerva Embeddings (minerva-embedding)

​API Reference

​Applications

​Usage Tips

​Minerva Scoring (minerva-score)

​API Reference

​Applications

​Usage Tips

​Minerva Sampling (minerva-sample)

​API Reference

​Applications

​Usage Tips

​Minerva Gradient (minerva-gradient)

​API Reference

​Applications

​Usage Tips

​Toolkit Notes

​Infrastructure Guides

Tool Persistence

Device Management

Parallel Execution

Background

Tools

Minerva Interactions (`minerva-interactions`)

API Reference

Applications

Usage Tips

Minerva Embeddings (`minerva-embedding`)

API Reference

Applications

Usage Tips

Minerva Scoring (`minerva-score`)

API Reference

Applications

Usage Tips

Minerva Sampling (`minerva-sample`)

API Reference

Applications

Usage Tips

Minerva Gradient (`minerva-gradient`)

API Reference

Applications

Usage Tips

Toolkit Notes

Infrastructure Guides
